MARINE ELECTRONICS Garmin ECHOMAP UHD 75sv

• See below and around your boat in incredible detail with included transducer.
• Navigate any waters with preloaded Canada LakeVü g3 inland maps.
• Share data and maps with select ECHOMAP devices on your network.
• Manage your marine experience from nearly anywhere.
• Control the most powerful trolling motor available.
• Create your own maps on the fly and tailor them to fit your needs.

Product Description:

General
PHYSICAL DIMENSIONS	9.8″ x 5.5″ x 2.0″ (25 x 13.9 x 5.1 cm)
DISPLAY SIZE	6.1″ x 3.4″; 7.0″ diagonal (15.5 x 8.6 cm; 17.8 cm diagonal)
DISPLAY RESOLUTION	400 x 800 pixels
DISPLAY TYPE	WVGA display
WEIGHT	1.7 lbs.(0.77kg)
WATER RATING	IPX7
MOUNTING OPTIONS	Bail or flush
POWER CONSUMPTION	15W
ANTENNA	Internal or external over NMEA 2000
TRANSMIT POWER	500 W (RMS) / 4,000 W (peak to peak)
RECEIVER	5 Hz
GARMIN MARINE NETWORK™ PORTS	1 Panoptix port

Maps & Memory
PRELOADED MAPS	LakeVü g3 (inland maps)
ACCEPTS DATA CARDS	1 microSD card; 32 GB maximum size
WAYPOINTS	5,000
TRACK LOG	50,000 points; 50 saved tracks
ROUTES	100



Whats in the Box:

• ECHOMAP UHD 75sv with LakeVü g3 for Canada
• GT56UHD-TM transducer
• Power/data cable
• Tilt/swivel mount with quick release cradle
• Flush mount
• Protective cover
• Hardware
• Documentation
